RJM Music Technology Mastermind PBC/6X

$1,299.00
IN STOCK
Love it, or swap within 14 days | Free Gravity Pick!

Free Shipping for orders over $199

Orders usually arrive in 2 - 3 days Free if spend over $199

Love it, or swap within 14 days

Don't like what you hear? No worries - swap within 14 days.

Best service in town

4.8 / 5 from over 150+ Google Reviews Buy from the best in AUS.

;

The Mastermind PBC/6X is our response to all of our customers who said “I like the PBC/10, but I want it smaller, less expensive, and I want to be able to change loop order on the fly!”

The PBC/6X allows you to connect 6 pedals and have complete flexibility in choosing which pedals are on at any time, as well as the order of those pedals in your signal chain. You can also control any MIDI compatible devices and switch channels on most amps that use 1/4-inch switching jacks.

The Mastermind PBC/6X features:

  • 6 audio loops, 3 of which are stereo capable
  • A buffered insert loop that can be used for a 7th pedal, or for special routing strategies like the “four cable method”
  • Matrix switching that allows reordering of loops
  • 2 function switches for amplifier channel control
  • An integrated tuner
  • A full-featured MIDI controller that can send any type of MIDI message

FEATURES

  • 6 audio loops
  • The last three loops are stereo capable using TRS jacks
  • Matrix switching for maximum routing flexibility
  • Flexible output that can be mono, stereo, or used as an A/B/Y switch
  • Mono mixdown feature allows you to mix down your stereo output to mono when using with a single amp
  • Two inputs, one with a switchable buffer
  • 7 buttons, each with a multi-color LED indicator
  • Buttons are user configurable – any button can be set to any function and LED color
  • Easy to read backlit LCD display that can display preset and song names, plus other status
  • Built in tuner
  • MIDI connection, powered by the MIDI “brain” of our Mastermind GT controller. This MIDI port can be split into a MIDI input and output using a special Y cable
  • USB device port for connection to a PC or Mac. This allows the Mastermind PBC to send MIDI commands to a computer, or to communicate with the Mastermind Editor software
  • A 1/4-inch TRS jack that provides two function switches. These can be used to control the channel switching and other features on an amplifier, or for externally switchable features on certain pedals
  • Expression pedal input that can be programmed to generate MIDI messages based on the position of the pedal
  • External switch input allows two more switches to be added. These switches can be programmed to perform any function the internal buttons can
  • Mac and PC editor software allows for faster and more comprehensive editing, including deep MIDI editing and changing button layouts
  • 3 year limited warranty

SPECS

  • 768 presets
  • 1000 songs, 64 setlists
  • Can control up to 16 MIDI devices
  • 20 MIDI messages can be assigned per button (PC, CC, Note, Sysex)
  • Dimensions: 10.1 (w) x 4.4 (d) x 2.4 (h) inches (25.7 (w) x 11.1 (d) x 6.1 (h) cm)
  • Weight: 2 lbs / 0.9 kg
  • Power Requirements: 9VDC or 12VDC 220mA, Boss-type connector (center negative 5.5/2.1mm barrel connector).
  • Comes with Australian Power Supply
